USED MACHINE QUOTATION

Sakai SNBM-540L 5Dies Parts former

Specifications:

Max. cut off diameter………………………………………………………………..24mm

Length under head..………………………………………………………………….25~160mm

Max. cut off length…………………………………………………………………….220mm

Diameter of Die………………………………………………………………………….120mm

Diameter of punch……………………………………………………………………90mm

K.O. length…………………………………………………………………………………190mm

P.K.O length……………………………………………………………………………….40mm

Crank diameter………………………………………………………………………….330mm

Ram stroke…………………………………………………………………………………360mm

PPM…………………………………………………………………………………………….60

Main motor…………………………………………………………………………………37kW

Machine weight…………………………………………………………………..………55ton

Machine dimensions……………………………………………………………………W4.0mxL6.0mxH2.0m
