Specifications:                                                                  Metric  Standard

Max. outer diameter for round parts...................          64mm............    2.519”

Max. outer diameter for combination blanks.....          55mm............    2.165”

Max. width accross flats (hex)...............................          56mm............    2.204”

Min. bar diameter...................................................          19mm............    0.748”

Max. bar diameter...................................................         40mm...........     1.574”

Min cutoff Length...................................................          20mm............    0.750”

Max cutoff Length..................................................          72mm............    2.834”

Drive motor rating.................................................           55kw.............    72HP

Center distance of dies...........................................         160mm.........     6.299”

Die diameters:

             1st and 3rd stations.....................................        125mm..........    4.921”

             2nd Station...................................................         150mm..........    5.905”

Main ram stroke......................................................          160mm..........    6.299”

Ejector Stroke..........................................................          70mm............    2.755”

Dimensions and weights (Including motor, without heater & conveyor):

Length................................        5000mm.......     196.8”

Width..................................       3700mm........    145.6”

Height................................        2000mm........    78.7”

Weight (w/Motor)...........        35,800.0kgs...   78,760.0lbs

Electrics:

                    main drive................    53KW

         power supply..........     380 volt 3 phase 50 cycles

Equipped with:

                                        - Variable Speed Drive

                                        - Bar feeding system

                                        - Product conveyor

                                        - Centralized controls

                                        - Split second safety stop

                                        - Overarm-type main slide

                                        - One piece steel casting bedframe

                                        - Electro-pneumatically operated clutch and brake

                                        - Automatic centralized pressure lubrication system

                                        - Induction heater

Condition........................................ Good

Location........................................... Overseas Plant Site
