Specifications:

Forging Pressure........................................................................220ton

Max. cut-off diameter................................................................21mm(mild steel)

Max. cut-off length....................................................................25mm

Min. Cut-off length....................................................................7mm

Max. product diameter...............................................................26mm

Max. across flats........................................................................22mm

Max. Punch diameter.................................................................65mm

Max. die diameter......................................................................110mm

Producttion rate.........................................................................200ppm

Motor output in Kw..................................................................52Kw

Dimension.................................................................................440x240cm

Net weight....................................................................................20TONS
